0.18mm/0.16mm/0.35mm Food Grade ETP & TFS with Enhanced Alkali & Rust Resistance

0.18mm/0.16mm/0.35mm Food Grade ETP & TFS with Enhanced Alkali & Rust Resistance

food grade tinplate sheets

rust resistant tinplate sheets

enhanced alkali resistance tinplate sheets

Menşe yeri:

Çin

Marka adı:

QuanJiang

Sertifika:

MILL CERTIFICATE

Model numarası:

0,18 mm alkali direnci

Bize Ulaşın

Bir teklif isteği
Ürün Detayları
Malzeme::
Bay, SPCC
Sertlik::
TS230, TS245, TS260, TS275, TS290, TH415, TH435, TH520, TH550, TH580, TH620
Öfke::
T1, T2, T3, T4, T5, DR8,DR7,DR9
Kalınlık::
0,15-0,46 mm
Kalay Kaplama::
1.1/1.1,2.0/2.0,2.8/2.8,5.6/5.6, vb. Veya müşteri
Yüzey::
Parlak, Taş, Mat, Şerit, Kaba Taş
Kullanmak::
Gıda ambalajı metal teneke kutu kapakları teneke alt kapak uçları
Paket::
ince plastik film + paslanmaz kağıt + metal kapak + metal açılar + kayışlar + palet
Ödeme ve Gönderim Koşulları
Min sipariş miktarı
25 ton
Fiyat
Negotiated
Ambalaj bilgileri
Ahşap palet, köşe korumalı denize elverişli standart. Müşterinin gereksinimlerine göre sayfa veya bo
Teslim süresi
Müzakere edilmiş
Ödeme koşulları
T/T
Yetenek temini
50000 MT/ay
Ürün Açıklaması
0.18mm/0.16mm/0.35mm Food Grade ETP & TFS with Enhanced Alkali & Rust Resistance
Product Description

This specialized line of Electrolytic Tin Plate (ETP) and Tin-Free Steel (TFS) is engineered for the critical role of manufacturing food can ends, lids, and bottom caps where exposure to corrosive contents is a constant challenge. The product is formulated to provide superior, dual-layer protection: first, against external environmental rust, and second, against internal chemical attack from alkaline or acidic food products like tomato paste, certain vegetables, sauces, and fruits. Available in precise, industry-standard thicknesses (0.16mm, 0.18mm, 0.35mm), this material delivers the optimal balance of structural strength for secure double-seaming and economic material usage. It serves as the reliable foundation for ensuring long-term food safety, flavor preservation, and container integrity throughout the supply chain and shelf life.

Features & Characteristics
  • Dual-Action Corrosion Defense: Specifically engineered to resist both atmospheric rust and internal corrosion from aggressive food contents, significantly reducing the risk of package failure.
  • Precision-Gauge Consistency: Produced in tightly controlled thin gauges (0.15-0.46mm) to optimize material yield and cost-efficiency while maintaining the mechanical integrity required for can sealing.
  • Tailored Internal Coatings: Designed to be paired with specialized internal lacquers (e.g., 202, 300, 401, 603 codes) that provide product-specific barriers against sulfide staining and chemical migration.
  • Excellent Forming Capability: Offered in a comprehensive range of tempers (T1-T5, DR7-DR9) to facilitate complex stamping and deep-drawing processes for end manufacturing without material fracture.
  • Superior Surface for Decoration: Available in various finishes (Matte, Stone, Bright) to ensure excellent adhesion for external protective varnishes and high-quality lithographic printing for branding.
Key Advantages

Implementing this chemically resistant tinplate directly enhances production reliability and end-product safety. It minimizes spoilage and recall risks by providing a robust barrier between the food and the metal. The material's lightweight nature reduces shipping costs, and its 100% recyclability supports corporate sustainability objectives. Furthermore, the ability to customize specifications—from temper and coating weight to internal lacquer type—allows for a perfectly tailored solution for any food product, from acidic fruits to alkaline prepared foods.

Technical Parameters Table
Parameter Specification
Material Type Electrolytic Tin Plate (ETP) / Tin-Free Steel (TFS)
Base Steel Grade MR, SPCC
Key Thickness 0.16mm, 0.18mm, 0.35mm (Range: 0.15-0.46mm)
Tin Coating Mass (ETP) 1.1/1.1, 2.0/2.0, 2.8/2.8, 5.6/5.6 g/m²
Temper Range T1, T2, T3, T4, T5, DR7, DR8, DR9
Hardness Range TS230-TS290, TH415-TH620
Surface Finish Bright, Stone, Matte, Silver, Rough Stone
Primary Application Food Can Ends, Lids, Bottom Caps
Frequently Asked Questions (FAQ)
  1. Q1: What makes this tinplate "alkali-resistant" for food cans?
    A1: The resistance is achieved through a combination of the base tin or chromium coating and the application of specifically formulated, food-approved internal lacquers (like epoxy-phenolic coatings). These lacquers are tested to create an inert barrier that withstands the chemical activity of alkaline products.

  2. Q2: Can I order this material with a specific internal coating already applied?
    A2: Yes. We can supply the tinplate pre-coated with standard internal lacquers such as 202 (for chili sauce), 300/401 (for tomatoes/fruits), or 603. Specifying your food product allows us to recommend the optimal coating system.

  3. Q3: What is the main difference in using ETP vs. TFS for can ends?
    A3: ETP provides excellent overall corrosion resistance and is easily solderable. TFS offers superior adhesion for internal organic coatings and exceptional resistance to sulfide staining (preventing darkening with certain foods), often at a lower material cost. The choice depends on your sealing technology and food content.

  4. Q4: What quality documentation is provided?
    A4: We supply a detailed Mill Test Certificate with every batch, confirming the chemical composition, mechanical properties (temper, hardness), coating mass, and dimensional compliance. This is your assurance of material quality and traceability.

  5. Q5: What information is needed to process an inquiry or order?
    A5: Please provide: material type (ETP/TFS), thickness, temper, coating weight, dimensions (width, coil ID or sheet size), surface finish, quantity, and the specific food application to determine the best internal coating recommendation.

Product Images & Applications
0.18mm/0.16mm/0.35mm Food Grade ETP & TFS with Enhanced Alkali & Rust Resistance 0
0.18mm/0.16mm/0.35mm Food Grade ETP & TFS with Enhanced Alkali & Rust Resistance 10.18mm/0.16mm/0.35mm Food Grade ETP & TFS with Enhanced Alkali & Rust Resistance 2

0.18mm/0.16mm/0.35mm Food Grade ETP & TFS with Enhanced Alkali & Rust Resistance 3

202 Chrome plate(Chilli sauce) 202 tin plating (tomato) 300 tin plating( tomato)

0.18mm/0.16mm/0.35mm Food Grade ETP & TFS with Enhanced Alkali & Rust Resistance 4

300 fruit tin plating( fruit) 401 tin plating( tomato) 401 tin plating( fruits)

0.18mm/0.16mm/0.35mm Food Grade ETP & TFS with Enhanced Alkali & Rust Resistance 5

603 tin plating( tomato) 603 tin plating( fruit)

LID WORKSHOP
0.18mm/0.16mm/0.35mm Food Grade ETP & TFS with Enhanced Alkali & Rust Resistance 6
0.18mm/0.16mm/0.35mm Food Grade ETP & TFS with Enhanced Alkali & Rust Resistance 7
Production Process
0.18mm/0.16mm/0.35mm Food Grade ETP & TFS with Enhanced Alkali & Rust Resistance 8
0.18mm/0.16mm/0.35mm Food Grade ETP & TFS with Enhanced Alkali & Rust Resistance 9
PARTNER
0.18mm/0.16mm/0.35mm Food Grade ETP & TFS with Enhanced Alkali & Rust Resistance 10
CERTIFICATE
0.18mm/0.16mm/0.35mm Food Grade ETP & TFS with Enhanced Alkali & Rust Resistance 11
